Kia PV5 Passenger 71.2 kWh(MY26)
Kia logo
Kia

Kia PV5 Passenger 71.2 kWh(MY26)

Available Van FWD
42.290 € $45,673£35,947
WLTP Range
315 km196 mi
Net Battery
67 kWh
0-100 km/h
10.6s
Peak Power
120 kW
A day with this car
DC 10–80%
39 min
150 kW peak · 75 kW avg
Home wallbox
7h 15m
11 kW AC · 0–100% overnight
Winter highway
227 km141 mi
Cold, 120 km/h class
Charge ports
CCS
Type 2 · front middle

One-stop highway day · 328 km204 mi in 3h 13min

225 km140 mi
2h 2min
15 min
charge
103 km64 mi
56min
WLTP Range
315 km196 mi
Official Combined
Usable Battery
67 kWh
71.2 kWh Gross
Peak Power
120 kW
161 hp
0-100 km/h
10.6 s
Max: 135 km/h84 mph
DC Fast Peak
150 kW
High-Power DC

Performance & Powertrain

FWD Dedicated EV Platform
Total System Power 120 kW (161 hp)
Total System Torque 250 Nm
0-100 km/h Sprint 10.6 s
Top Speed 135 km/h84 mph
Drivetrain Configuration FWD
Platform Code HMG E-GMP.S

Battery Engineering & Chemistry

400 V NMC
Usable Battery Capacity 67 kWh
Nominal Battery Capacity 71.2 kWh
Battery Type Lithium-ion
Cell Form Factor No Data
Nominal Voltage No Data
Total Cell Count No Data
Pack Configuration No Data
Manufacturer Battery Warranty 7 years / 150,000 km93 mi

Dimensions, Cargo & Towing

Towing: 1500 kg Frunk: 0 L0.0 cu ft
Boot Cargo Volume 1330 L47.0 cu ft
Max Cargo (Seats Down) 3615 L127.7 cu ft
Front Trunk (Frunk) 0 L0.0 cu ft
Unladen Curb Weight 2,145 kg4,729 lbs
Overall Length 4695 mm184.8 in
Width (with mirrors) 2255 mm88.8 in
Overall Height 1923 mm75.7 in
Wheelbase 2995 mm117.9 in
Towing Capacity (Braked) 1,500 kg3,307 lbs
Towing Capacity (Unbraked) 750 kg1,653 lbs
Gross Vehicle Weight (GVWR) 2600 kg5,732 lbs
Max Payload Capacity 530 kg1,168 lbs

Cabin, Chassis & Thermal Management

Seating Capacity 5 people seats
Isofix Anchor Points Yes, 2 seats
Turning Circle 11.7 m38.4 ft
Market Segment N - Passenger Van
Roof Rails No
Heat Pump Standard Equipment

Estimated Range by Weather & Road

Efficiency: 213 Wh/km343 Wh/mi

Estimates, not measurements: the WLTP figure scaled by the same temperature and road factors for every car (for example 65% for cold motorway driving, 115% for mild city driving). Your range depends on speed, wheels, load and heating. For a planned stop, use the charging simulator.

Estimated Range Envelope
Cold Highway: 205 km127 mi | Mild Urban: 362 km225 mi
Worst-Case Winter Highway WLTP Lab: 315 km196 mi Best-Case Mild Urban
❄️ Cold Winter (-10°C)
Cabin Heat On
City Driving
Urban stop-and-go
233 km145 mi
Highway Cruising
Motorway speeds
205 km127 mi
Combined Cycle
Everyday winter commute
221 km137 mi
☀️ Mild Summer (23°C)
Optimal Temperature
City Driving
Peak regen recovery
362 km225 mi
Highway Cruising
Motorway speeds
258 km160 mi
Combined Cycle
Ideal mixed-use range
302 km188 mi
High-Power Road Trips

DC Ultra-Fast Charging (10% to 80%)

⚡ CCS2 High-Power
Peak Intake
150 kW DC
Maximum Power
10-80% Session
39 min
Typical Road Stop
Average Power
75 kW DC
Sustained Rate
Range Added
330 km/h205 mph
Added per Hour
Plug & Charge (ISO 15118) No Data
Battery Preconditioning Auto via Nav
Autocharge Protocol Yes
Home & Overnight

AC Destination & Wallbox Charging (0% to 100%)

Type 2 Inverter
Max AC Power
11 kW AC
3-Phase Wallbox
0-100% Duration
7h15m
Full Overnight Charge
Charge Speed
44 km/h27 mph
Range per Hour
Port Location
Front Side - Middle
Body Placement
Mobile Power Station

Bidirectional Charging Capabilities (V2X)

V2L (Vehicle-to-Load)
Camping & devices
3.6 kW AC
V2H (Vehicle-to-Home)
Emergency backup
Not supported
V2G (Vehicle-to-Grid)
Grid arbitrage
Not supported

Highway Endurance Score

EVDB Index
2.0/ 5.0
Moderate Highway Feasibility

Calculated from sustained 10-80% DC fast charging speed, cold-weather aerodynamic drag, and official WLTP range (315 km196 mi).

Vehicle Overview

  • Manufacturer Kia
  • WLTP Range 315 km196 mi
  • Net Battery 67 kWh
  • DC Fast Charging 150 kW
  • Towing Capacity 1,500 kg3,307 lbs
  • Market Availability Available
  • Release Date 5/1/2025
  • Telemetry Verified 5/18/2026
Frequently Asked Questions

Kia PV5 Passenger 71.2 kWh(MY26) Range & Charging FAQ

What is the real-world highway and winter range of the Kia PV5 Passenger 71.2 kWh(MY26)?

The official combined WLTP range for the Kia PV5 Passenger 71.2 kWh(MY26) is 315 km (196 miles).

In cold winter conditions (-5°C / 23°F) at highway cruising speeds (120-130 km/h), expect a realistic highway range of approximately 227 km (141 miles) due to cold battery chemistry, cabin heating, and higher aerodynamic drag.

How long does it take to charge the Kia PV5 Passenger 71.2 kWh(MY26) at home?

Charging the 67 kWh battery from 0% to 100% takes approximately 5.5 hours using a standard 11 kW 3-phase AC wallbox. On a single-phase 7.4 kW home charger, a full charge takes around 8.1 hours (typically overnight).

How fast is DC fast charging (10% to 80%)?

The Kia PV5 Passenger 71.2 kWh(MY26) supports peak DC fast charging rates of up to 150 kW. Recharging from 10% to 80% State of Charge (SoC) requires approximately 26 minutes at a compatible ultra-rapid charging station.

How much does it cost to charge the Kia PV5 Passenger 71.2 kWh(MY26)?

At an average European residential electricity tariff of €0.24/kWh, a complete 0-100% home charge costs approximately €16.08. At high-power public DC charging networks (~€0.65/kWh), a full recharge costs approximately €43.55.
